20T Single Arm Gantry Hydraulic Press
20T single arm gantry hydraulic press
This press is suitable for pressing, correcting, stretching, bending, forming, blanking, flanging and other stamping processes. It is also suitable for press forming processes such as powder metallurgy, auto parts, household appliances, kitchen utensils, etc.
| Technical Parameters | Y41-20T | Y41-40T | Y41-60T | Y41-100T | Y41-200T | Y41-315T | |
| Nominal pressure(KN) | 200 | 400 | 600 | 1000 | 2000 | 3150 | |
| Slider stroke(mm) | 260 | 280 | 280 | 320 | 360 | 600 | |
| Maximum opening height(mm) | 400 | 460 | 480 | 500 | 600 | 1000 | |
| Throat depth(mm) | 230 | 230 | 250 | 250 | 300 | 360 | |
| Effective size of workbench (mm) |
The left and right sides | 520 | 520 | 520 | 600 | 600 | 1000 |
| The front and rear sides | 420 | 420 | 420 | 450 | 500 | 700 | |
| Motor power(KW) | 3 | 5.5 | 5.5 | 7.5 | 11 | 15 | |
use:
Used for disassembly, forming, straightening, and stretching in the machinery industry. Main features: advanced welding technology, large up and down movement space, easy to press the workpiece, preset working pressure, can be equipped with electronic digital tonnage display, hydraulic system The pressing work of heat dissipation device, sheet metal forming, and one-time cold riveting forming of split angle teeth are essential pressure equipment in modern auto repair industry.
