200T Four Column Hydraulic Press
The hydraulic press has a three-beam four-column hydraulic press with galvanized sheet as the base plate, the workbench and slider are integral 45# cast steel, the galvanized sheet is the base plate, and the high-quality environmentally friendly polyester baking paint is used as the main cylinder of the hydraulic press. The cylinder is 45# steel, forged
Send Inquiry
Product Details of200T Four Column Hydraulic Press
200 tons of powder forming hydraulic press
A 200T Four Column Hydraulic Press is a machine tool powered by hydraulic oil. Depending on the application, the machine's structure and configuration vary. The work surface, opening, and stroke required for each 200T hydraulic press are custom-designed for a wide range of applications.
Hydraulic Press Parameters
| Technical Parameters | Y32-200T | |
| Nominal pressure(kN) | 2000 | |
| System pressure(MPa) | 25 | |
| Slider stroke(mm) | 500 | |
| Maximum opening height(mm) | 800 | |
| Effective table size (L×W)(mm) | Left and Right | 720 |
| Front and Rear | 700 | |
| Slider speed(mm/s) | Idle stroke | 120 |
| Feeding speed | 14 | |
| Return speed | 72 | |
| Ejection force(kN) | - | |
| under cylinder stroke(mm) | - | |
| Motor power(KW) | 11 | |
Products Details
1. The 200T Four Column Hydraulic Press is a three-beam, four-column model equipped with a main cylinder and a top cylinder.
2. The 200-ton four-column hydraulic press utilizes welded steel plates tempered in a heat-aging furnace for high precision and deformation resistance.
3. The cylinder body and piston rod are high-strength forgings to ensure performance. The cylinder inner wall is rolled, while the piston rod and column are tempered, quenched, and chrome-plated.
4. The operating pressure and stroke can be adjusted within a certain range as needed.
5. It features independent electronic and hydraulic systems, centrally controlled by push buttons, enabling both electric and semi-automatic operation.
6. The hydraulic control system utilizes a high-efficiency integrated cartridge valve system, offering low internal resistance, a simple structure, high flow, and reduced leak points.
7. The key electrical components of the 200-ton four-column hydraulic press's electronic control system are all well-known domestic and international brands, ensuring long-term reliable operation.
8. The four-column hydraulic press features integrated mechanical, electrical, and hydraulic safety devices, ensuring superior safety.
Optional Configurations
Hydraulic presses can be customized to suit the product being pressed. If you require additional configurations, please contact us for a complete technical solution.
Cooling system
Automatic loading device
Automatic unloading device
Customized molds
Infrared protection function
Powder molding molds
Servo drive motors
Stretch forming molds
Application
200T Four Column Hydraulic Press can be divided into powder forming hydraulic presses and metal stretch forming hydraulic presses
1. Powder and Granule Pressing/Molding: Suitable for pressing materials such as livestock salt licks, metal powders, ceramic powders, fishing bait, nutrient-rich soil, bath bombs, and medicinal powders.
2. Metal Sheet Drawing and Deep Drawing: Used for forming products such as stainless steel sinks, carts, cover plates, radomes, and serving trays.
Stretch forming hydraulic presses
Powder forming hydraulic presses
